Etched Tapes Out AI Inference Chip, Secures $1 Billion Demand

Etched - Building AI Hardware to Make Inference Faster and Cheaper - [Invest Like the Best, EP.480] — Colossus | Investing & Business Podcasts

Colossus | Investing & Business Podcasts

Inference startups will displace general-purpose GPUs by optimizing custom racks and cluster-scale memory to solve data-movement bottlenecks at megawatt scale.

AI-assisted summary of Etched - Building AI Hardware to Make Inference Faster and Cheaper - [Invest Like the Best, EP.480] — original source. Check the original for full context.

Source published:

Detailed notes

## Background This episode of Invest Like the Best was published on June 30, 2026, by Colossus on RSS/web, hosted by Patrick O'Shaughnessy. The episode features an interview with Gavin Uberti and Rob Wachen, the young founders of Etched, exploring how they built a post-ChatGPT AI hardware startup, taped out a chip on their first try, and scaled customer demand to over $1 billion.

## TL;DR Gavin Uberti and Rob Wachen detail the founding, technical strategy, and rapid growth of Etched, a startup developing specialized hardware and complete server racks for AI inference. They discuss their core architectural decisions—such as Prefill-Decode Disaggregation and Low Voltage Inference—designed to bypass general-purpose GPU limitations and optimize for tokens-per-watt. The founders also share how they recruited industry veterans, overcame extreme engineering and supply chain hurdles in Bangalore and Taiwan, and raised record-breaking capital to build gigawatt-scale AI infrastructure.

## Atmosphere & style The conversation is energetic, candid, and intellectual, striking a compelling balance between high-stakes hardware engineering and deeply personal human stories. Gavin and Rob display an infectious, 'healthy naivety' paired with rigorous technical mastery, while host Patrick O'Shaughnessy guides the discussion with enthusiastic curiosity. The tone shifts seamlessly from intense grit—like crunching through a 50-picosecond clock alignment crisis or funding physical design prep—to profound introspection when reflecting on early adversity and life-or-death decisions.

## Key takeaways - `03:54` By questioning legacy semiconductor assumptions and removing standard EDA software buffers, Etched recaptured massive performance gains across the chip stack. - `07:52` Etched's architecture relies on two key technical bets: Prefill-Decode Disaggregation (PD Disag) and Low Voltage Inference to eliminate thermal throttling. - `14:15` Serving real-time inference at sustainable economics and megawatt-scale efficiency is the primary bottleneck to scaling global AI deployment. - `15:00` Achieving orders-of-magnitude reductions in multi-chip interconnect latency allows clusters to generate tens of thousands of tokens per second. - `25:00` Vertical integration—building chips, boards, power delivery, and cold plates in-house—is central to Etched's strategy to move faster than competitors. - `30:00` By pairing unconstrained young engineering talent with veteran chip architects, Etched successfully built an elite, specialized hardware team. - `34:30` Etched sent a dozen engineers to live in Bangalore for six months to bypass external vendor delays and maintain a 24-hour development cycle. - `37:30` Through parallel execution and software emulation on 700+ FPGAs, Etched compressed its silicon bring-up time to just 40 days. - `40:00` Data center power limits have made throughput per megawatt and user concurrency the primary metrics for next-generation enterprise hardware. - `48:38` Etched took a 'kernels-first' approach to software, skipping complex compiler abstractions to optimize directly for dominant AI architectures. - `01:35:43` During silicon bring-up, engineers solved a complex clock domain defect by aligning independent clock signals to within 50 picoseconds. - `01:40:00` After every major VC passed on their Series A pitch, Etched leveraged vendor financing and HFT backer validation to secure $103M in commitments. - `01:35:00` Gen 1 avoids supply chain bottlenecks by using TSMC's 4nm process and alternative memory lines, while Gen 2 targets gigawatt-scale production. - `02:03:44` Future AI economics will scale toward trillion-dollar data centers evaluated on 'agents per megawatt' as machine intelligence scales globally.

## Detailed walkthrough ### `00:00` Welcome to Invest Like The Best

Patrick O'Shaughnessy opens the episode by highlighting podcast sponsors Ramp, Felix by Rogo, and WorkOS, emphasizing how these platforms streamline financial operations, automate complex enterprise workflows, and fast-track enterprise readiness for fast-growing technology companies.

O'Shaughnessy introduces *Invest Like the Best* as an open exploration of markets, ideas, stories, and strategies designed to help listeners invest their time and money more effectively. He notes that listeners seeking deeper insights can subscribe to *Colossus*, a quarterly publication featuring in-depth profiles of the business and investing leaders shaping today's commercial landscape.

- Ramp offers an integrated finance platform that delivers an average of 5% in annual savings and helps client businesses grow revenue 3.2 times faster than average. - Felix by Rogo acts as an autonomous personal finance agent capable of turning simple prompts into finished, client-ready Excel models, PowerPoint decks, and sourced research. - WorkOS enables modern AI and software platforms—including OpenAI, Perplexity, and Cursor—to become enterprise-ready overnight with turnkey SSO, SCIM, and RBAC infrastructure. - Patrick O'Shaughnessy is the CEO of Positive Sum (`PSUM.VC`), and opinions expressed on the show are strictly for informational purposes.

---

`02:07` Gavin Uberti and Rob Wachen

Patrick introduces his guests, Gavin Uberti and Rob Wachen, the co-founders of Etched. Reflecting on his first conversation with Uberti three years earlier, O'Shaughnessy recalls being fascinated by their ambitious vision to build custom silicon. When he began vetting the company for potential venture investment, industry veterans and experts almost universally dismissed the idea. The prevailing consensus in semiconductors held that successful chip startups required founders in their 40s or 50s who had spent decades shipping multiple generations of complex silicon.

Despite total skepticism from incumbents and traditional venture capital, Etched defied expectations. They became the first hardware startup founded after the launch of ChatGPT to successfully tape out a working chip on its very first attempt. Today, Etched has secured over $1 billion in customer demand for its flagship hardware and raised $800 million in capital. Their core product is not merely a standalone accelerator, but a fully integrated, vertically engineered inference rack encompassing chips, specialized circuit boards, high-efficiency power delivery systems, ultra-low-latency interconnects, and scalable manufacturing infrastructure.

> "A few years ago, when they set out to build a better AI chip than the largest companies in the world, almost everyone I called told me it could not be done."

---

`03:54` Two 21-Year-Olds Taking on NVIDIA

Recalling the early days of facing down an entire industry of doubters, Uberti explains that overcoming these odds required a necessary degree of healthy "naivety." When incumbent engineers asserted that a tiny team of 21-year-olds could not out-design NVIDIA, Uberti and Wachen continually pressed on *why* specific limitations existed. They quickly realized that the semiconductor and data center ecosystems are built on massive layers of historical "buffer." Standard Electronic Design Automation (EDA) tools, standard cells, power modules, and printed circuit boards (PCBs) are intentionally engineered to be general-purpose, accommodating everything from sub-zero outdoor IoT deployments to generic cloud servers.

By challenging these legacy assumptions and optimizing strictly for data center AI workloads, Etched unlocked massive performance gains. Uberti cites a concrete example in timing sign-off and clock speed validation. EDA tools by default mandate timing checks across thermal "corners" that include freezing zero-degree Celsius conditions. Because data center GPUs and AI accelerators never operate near freezing temperatures—typically running at or above 80 degrees Celsius—eliminating irrelevant constraints allows engineers to recapture 20% here, 50% there, and 2x elsewhere across the system design stack.

Wachen points out that industry reactions fell into two distinct camps: those who relied strictly on age-based heuristics and refused to entertain the possibility, and truth-seeking experts willing to test the underlying physics. He recounts meeting Mark Ross, the former CTO of Cypress Semiconductor (which sold for $10 billion). When the founders first pitched Ross in their college dorm room, Ross initially scoffed at the idea of beating NVIDIA. However, he challenged them to write a detailed white paper and construct a functional architectural simulation. After nights of intense work, they presented a simulation that proved the concept worked. Impressed, Ross advised them that they needed at least $3 million to start; after they raised $5 million, Ross joined first as an advisor and ultimately became Etched's full-time CTO.

- Standard EDA sign-off software mandates thermal corner testing at 0°C, whereas operational AI data center chips run consistently above 80°C. - Compounding small efficiency gains across custom power, board layout, and silicon constraints generates massive systemic performance advantages. - Former Cypress Semiconductor CTO Mark Ross was convinced after reviewing Etched's functional architectural simulation, eventually joining as CTO. - Etched raised an initial $5 million seed round to initiate chip development after Ross's early validation.

---

`07:52` The Two Technical Bets Behind Their Architecture

Uberti and Wachen detail the fundamental architectural bets driving Etched's system design. Rather than selling a standalone PCIe card or chip, Etched manufactures an end-to-end inference rack optimized around the two primary phases of running Large Language Models (LLMs): **Prefill** and **Decode**. Prefill is compute-heavy, reading in massive prompt contexts to construct the Key-Value (KV) cache; Decode is memory-bandwidth-bound, sequentially generating output tokens one by one using that cached context.

To maximize throughput across both phases, Etched employs **Prefill-Decode Disaggregation (PD Disag)**. One dedicated server cluster processes pre-fills at ultra-high speed, then transfers the resulting KV cache memories across a high-speed network to a specialized decode cluster that fires off output tokens. Uberti compares this process to "loading the gun and then firing it." While competitors argue over isolated metrics like SRAM vs. High Bandwidth Memory (HBM) or 3D DRAM packaging, Etched evaluated every trade-off—recognizing that thermal density, supply chain bottlenecks, and interconnect latency mean there is no "free lunch" in hardware packaging.

``` +--------------------------------------------------------------------------------+ | ETCHED SYSTEM ARCHITECTURE | +--------------------------------------------------------------------------------+

[ PREFILL CLUSTER ] [ DECODE CLUSTER ] High Flop / Low-Voltage Engine Cluster-Scale Memory / Low Latency +--------------------------------+ +--------------------------------+ | - Process massive prompt text | | - Read pre-filled KV Cache | | - Generate KV Cache | =======>| - Generate output tokens | | - Maximize Flops Utilization | Inter- | - Ultra-fast token delivery | | - Low Voltage (Denard scale) | connect| - Shared SRAM/HBM pool | +--------------------------------+ +--------------------------------+ ```

On the Prefill side, performance is dictated by real-world Model Flops Utilization (MFU). Traditional GPUs typically achieve only 20% to 50% MFU on real workloads because high gate activity increases thermal output, forcing the chip to thermal throttle its clock speed. Applying **Denard scaling** principles—where power consumption scales quadratically with voltage ($P \propto V^2$)—Etched developed a proprietary silicon power delivery method called **Low Voltage Inference**. By running their silicon at less than half the operating voltage of standard GPUs, they prevent thermal throttling and pack far higher functional flop density into the same die area.

For Decode, speed depends entirely on cluster-wide memory bandwidth and round-trip latency. Traditional GPU clusters incur massive latency overheads when hopping between nodes (e.g., up to 4,000 nanoseconds point-to-point on NVIDIA Blackwell systems), sharply diminishing returns when scaling tensor parallelism (TP). Etched solved this by engineering a fully custom, end-to-end interconnect stack from layer two up. By reducing point-to-point interconnect latency by more than 5x, Etched enables a multi-chip scale-up cluster to operate as a single unified memory pool (**Cluster Scale Memory**), dramatically lowering time-per-token generation speeds.

> "If I 2x my voltage, my power goes up by 4x. If I cut my voltage in half, my power goes down by a quarter... we were able to create a new mechanism of running at much lower voltages, a new type of power delivery that we call low voltage inference."

- **Prefill Phase:** Computes the prompt text and creates the KV cache; bottlenecked by functional matrix multiplication Flops and thermal limits. - **Decode Phase:** Generates output tokens sequentially; bottlenecked by memory bandwidth and cross-chip interconnect latency. - **Low Voltage Inference:** Operates at less than 50% of the operating voltage of conventional GPUs, eliminating thermal throttling and drastically improving MFU. - **Cluster Scale Memory:** Custom layer-2+ interconnect architecture cuts point-to-point cluster latency by >5x compared to the ~4,000 ns latency seen on Blackwell GPUs.

---

`14:15` Why Inference Becomes the Biggest Market

Zooming out to the broader macroeconomic landscape, the founders explain why inference infrastructure will dwarf traditional compute markets over the coming decade. Uberti emphasizes that humanity has arrived at a structural turning point where AI models are genuinely capable of solving complex logic problems, assisting in scientific discoveries, and democratizing access to education and medical care. The ultimate bottleneck to deploying this power globally is no longer pure model training, but serving real-time inference at sustainable economics and megawatt-scale efficiency.

- Global economic impact hinges on transitioning AI models from offline research experiments into real-time, ultra-fast production applications. - Reducing cost-per-token and maximizing tokens-per-watt are the core prerequisites for scaling AI access to billions of concurrent users.

`15:00` Scaling Token Generation: Memory Bandwidth and Economies of Scale

Gavin Uberti and Rob Wachen explain how faster decode speeds and cluster-scale memory bandwidth can compress a year's worth of scientific innovation into a single month. While today's inference clusters typically max out at eight chips or an NVL72 domain, future deployments will require thousands or tens of thousands of networked chips operating concurrently. Serving billions of users at thousands of tokens per second requires optimizing latency across the entire stack—from transistor to token—so chips communicate as seamlessly across a cluster as they do internally.

Drawing an analogy to consumer manufacturing, Gavin notes that tokens are currently being produced using general-purpose hardware like "screws back in the Renaissance." Just as economies of scale made iPhones and automobiles accessible to everyone without sacrificing quality, bringing industrial-scale efficiency to token production will democratize access to elite AI models. Rob adds that latency-sensitive products, like real-time coding assistants, require high per-token speeds; without pushing the hardware performance curve outward, providers will be forced to either throttle bandwidth or downgrade the user experience.

- **Global AI Adoption Gap:** Only a few million people currently hold paid AI subscriptions, representing roughly 1/1,000th of the global population. - **Data Movement Bottleneck:** Achieving 10,000 to 20,000 tokens per second across massive clusters requires multi-chip interconnect latency to be reduced by orders of magnitude. - **Vanta (Sponsor):** Security and compliance automation platform used by over 16,000 companies (including Ramp, Cursor, and Harvey) to streamline vendor risk assessments and continuous audits; offering $1,000 off at `[vanta.com/invest](https://vanta.com/invest)`. - **Ridgeline (Sponsor):** Unified cloud platform and system of record with embedded AI for investment management accounting, trade execution, and compliance; available at `ridgeline.ai`.

---

`20:00` Origins: Battling Cancer and Building Kernel Optimizers

Rob shares his deeply personal motivation for entering the AI hardware space. At the end of his sophomore year of high school, a martial arts injury led to the discovery of a tumor, leading to a diagnosis of stage four bone cancer with a under 30% survival rate. After undergoing two years of aggressive chemotherapy, surgeries, and relearning how to walk, his perspective on life shifted permanently. Later in college, when ChatGPT launched, Rob uploaded a pre-diagnosis photo of the tumor on his back to GPT-4's new vision feature. The model instantly identified it as a potential tumor and advised getting an immediate MRI—a diagnosis that had originally taken human doctors six months to reach. When he hit an immediate daily credit limit right after showing his parents, he realized the massive global demand for AI would instantly break existing, retrofitted hardware infrastructure.

Simultaneously, Rob ran Prod, a startup incubator that helped back early breakout companies like Cursor, Anysphere, and Mercor. Observing that every startup was spending the majority of its capital on compute costs, he concluded that inference would become the primary cost structure (COGS) for all future software, driving a multi-decade shift toward dedicated inference architectures. Meanwhile, Gavin started his career at age 17 writing low-level kernels at Xnor.ai (acquired by Apple for $200 million) and later OctoML (acquired by NVIDIA for hundreds of millions of dollars). Through kernel development, Gavin realized that while the underlying math of AI is simple, high-speed decode speed is entirely a data movement problem—inspiring Etched's focus on custom cluster-scale memory architectures.

- **Rob's High School Medical Crisis:** Diagnosed with stage four bone cancer at age 16 with a sub-30% survival rate; underwent two years of treatment and physical rehabilitation. - **Early AI Validation:** GPT-4 Vision correctly flagged Rob's bone cancer bump in seconds, contrasting with the six-month diagnostic ordeal he faced in real life. - **Gavin's Kernel Engineering Path:** Started at 17 at Xnor.ai ($200M Apple acquisition) and OctoML (NVIDIA acquisition), focusing on low-level chip kernel optimization and data flow. - **Prod Incubator:** Incubated notable AI-native startups including Cursor, Anysphere, Mercor, and Etched.

---

`25:00` Extreme Parallelism: Robot Competitions and Vertical Integration

Gavin recounts how he and his high school teammate, Sanford, competed in the FIRST Tech Challenge (FTC). Instead of running a traditional 20-person school team focused on documentation and community outreach awards, the two of them branched off to form a hyper-specialized two-person team. They chose to ignore non-technical scoring criteria, focusing exclusively on building a robot that scored the maximum number of points by completely redesigning the machine every three months. Their relentless focus earned them a world record for the highest score and an OPR ranking as the third-best software development team in the world.

That same philosophy—relentless speed, small elite teams, and complete parallelization—serves as the blueprint for how Etched operates. Rather than relying on third-party vendors, Etched adheres to the principle that "the best vendor is no vendor," choosing to vertically integrate everything from chips, printed circuit boards (PCBs), and cold plates to system interconnects and factory manufacturing. Gavin and Rob note that Etched is the only startup building its own rack-scale system alongside its custom chip from day one, bringing on industry veteran Brian Kelleher (who previously led NVIDIA's HGX and DGX systems engineering) to lead the effort.

- **FTC World Record:** Gavin and his partner Sanford achieved the world's highest FTC match score with a two-person team, completely redesigning their machine every three months. - **Thermal Validation Strategy:** Before silicon returned from the foundry, Etched manufactured dummy thermal chips with identical hotspot profiles to test and overpressurize custom cold plates, resulting in zero leaks post-tapeout. - **In-House Infrastructure:** Etched operates a 2-megabyte data center inside their office and a factory team in Taiwan, running 24/7 day and night shifts to accelerate hardware bring-up. - **Recruiting "The Legends":** Etched uses a strategy called "project recruiting," mapping out the hardest technical problems in hardware history to target and persistently recruit the top engineers in the world.

`30:00` Pairing Industry Legends with Raw First-Principles Talent

To execute on such a massive hardware undertaking, Etched mapped out every team at NVIDIA associated with rack-scale products to recruit veteran leadership. They targeted three specific leaders: two had just retired, and the third, Brian—who had founded and led NVIDIA’s HGX and DGX teams responsible for tens of billions in quarterly revenue—was planning one final chip generation before retiring. Etched successfully convinced Brian to join, bringing irreplaceable institutional memory to the startup. Having seen scale at the highest level, Brian frequently flags costly pitfalls, offering "billion-dollar lessons" that save the young company valuable development cycles. The other two NVIDIA veterans ended up investing in the company.

Etched pairs these seasoned industry legends with aggressive, first-principles young engineers—a dynamic summarized by their motto, "chips on shoulders, put chips in data centers." A prime example is Sanford, Gavin’s former high school world robotics championship teammate. While finishing his senior year of college, Sanford visited Etched for a week and was challenged to build a liquid-cooling cold plate within seven days—a task traditional thermal engineers would consider impossibly naive. Sanford built a functional contraption within the week that successfully de-risked a vital power delivery question. Combining fearless, unconstrained problem-solvers who "don't know where the bodies are buried" with battle-tested veterans creates a unique operational synergy.

- Brian previously built NVIDIA's HGX and DGX product lines, which drive tens of billions of dollars in revenue per quarter. - Sanford and Gavin were world robotics champions in high school together before Sanford designed a cold plate prototype in one week during his senior year of college. - The company's recruiting ethos focuses on pairing young, unconstrained talent driven by a point to prove with veteran chip architects.

`32:00` The Self-Selecting Culture of a High-Stakes Bet

Recruiting for a pre-product hardware company taking on NVIDIA requires a self-selecting culture of candidates who are undeterred by extreme risk. Etched avoids opportunistic hires looking for liquid, predictable compensation at established tech giants. Because potential hires must convince their families to relocate to San Jose, live in startup housing, and work under two 24-year-olds in an unprecedentedly supply-constrained semiconductor market, the talent funnel naturally filters out non-believers.

The team is united by a deeply personal drive to prove their supporters right rather than merely proving doubters wrong. The co-founders note that prospective hires who perform deep diligence and still choose to join are "wired differently" and thrive in an intense, high-stakes environment where they aim to deliver a 10x performance improvement rather than marginal gains.

- Prospective hires leave comfortable, highly liquid compensation packages to move into company housing programs in San Jose. - The hiring bar naturally weeded out conventional candidates, attracting engineers motivated by high-conviction, contrarian hardware architecture.

`34:30` Extreme Urgency and the Bangalore Rescue Mission

Etched treats the company itself as a machine engineered to rapidly produce iterative generations of hardware. When a critical third-party vendor fell nearly a year behind schedule right before chip tape-out, traditional options—waiting out the delay or switching vendors—would both derail timelines by a year. Instead, Etched created a third option: they dispatched a dozen of their top engineers to live in Bangalore, India, alongside the vendor for six months. Gavin personally relocated to Bangalore for four and a half months to oversee operations directly.

The team established an intense round-the-clock development cycle between India and the United States. Engineers in Bangalore walked through busy streets early every morning to be first in the vendor's office, audited incoming code, built custom acceleration tools, and made real-time design decisions without waiting for 12-hour cross-time-zone feedback loops. At 8:00 AM and 8:00 PM daily, the US and India teams held structured handover Zoom calls to maintain a continuous 24-hour engineering workflow. While competitor chips tied to that same vendor suffered multi-year delays, Etched successfully taped out on time.

- Gavin lived in Bangalore for 4.5 months, leading a team of 12 engineers sent overseas for up to a year. - Hand-off Zoom syncs occurred twice daily at 8:00 AM and 8:00 PM to maintain a seamless 24-hour continuous work cycle across time zones. - Competitors relying on the same external vendor faced multi-year delays and missed tape-out deadlines. - The team emphasizes delegating heavy decision-making authority to on-site engineers because "speed wins" over waiting for perfect, delayed answers.

`37:30` Prefetching Execution and Reducing Time-to-Inference to 40 Days

To maximize execution velocity, Etched practices "prefetching"—aggressively spending capital to parallelize every development task that can be completed before physical silicon arrives. Recognizing that every day off the market leaves massive revenue on the table, the team built their entire software stack, server racks, and production line in advance. They shipped fully configured server racks—complete with networking, CPUs, and storage—to customer data centers ahead of time, built a custom thermal mock chip to optimize cold plate cooling systems, and executed multiple circuit board revisions.

To simulate the unreleased hardware, Etched deployed an immense cluster of over 700 FPGAs to run their complete inference stack across a dozen AI models. While a major competitor took 10 months from receiving silicon to running inference inside a rack, Etched accomplished the milestone in just 40 days. To achieve this, over half the company lived adjacent to the office and operated continuous 24/7 day and night shifts, working around the clock from 10:00 AM to midnight and midnight to 10:00 AM.

- Etched utilized a cluster of over 700 FPGAs to emulate their full reticle chip and test a dozen models on their software stack prior to silicon arrival. - Bring-up time from silicon receipt to running inference in a data center rack was compressed to 40 days, compared to a competitor's reported 10-month timeline. - Operations ran continuously on two shifts (10:00 AM to 12:00 AM and 12:00 AM to 10:00 AM), with over half of the team residing right next to the office.

`40:00` Supply Chain Dynamics, TSMC Partnership, and Power Efficiency

Navigating global supply chain constraints requires deep, hands-on collaboration with key manufacturing partners rather than transactional vendor relationships. Highlighting TSMC's industry-leading customer service, Etched shared how TSMC ran a yield-improvement experiment on their own dime based on a technical suggestion from Etched's team; after validating higher yields, TSMC updated the manufacturing line.

Beyond silicon fabrication, data center power availability has become the primary bottleneck for scaling AI infrastructure. With massive power shortages making 500-megawatt data centers scarce, the critical metric for customers evaluating hardware is throughput per megawatt at a fixed level of interactive speed (ISO-interactivity). While earlier infrastructure phases prioritized raw token speed, the next wave of AI chips focuses on maximizing concurrency—allowing data center operators to run an order of magnitude more concurrent software agents per megawatt than legacy architectures.

- TSMC ran semiconductor yield optimization experiments funded on their own dime following suggestions from Etched engineers. - Power constraints have elevated throughput per megawatt and ISO-interactivity as the core metrics for enterprise data center deployments. - Etched's architecture aims to deliver an order-of-magnitude increase in user concurrency per megawatt compared to traditional GPU clusters.

`45:00` Wall Clock Time, Latency Limits, and Token Factories

Shrinking the time required for complex AI runs fundamentally changes what researchers can attempt. Gavin emphasizes that accelerating models—such as the AI that recently proved a longstanding conjecture in mathematics—transforms years-long compute timelines into months, weeks, or even days. In frontier research, "wall clock time" (the duration from starting an experiment to receiving data back) dictates the speed of scientific progress. Rob points to Cursor’s demonstration of coding agents building an entire web browser from scratch in a week as an indicator of where parallel autonomous agents are headed, noting that such tasks will soon take less than an hour.

When examining the absolute physical limits of chip performance, current industry architectures leave substantial room for optimization. In standard NVIDIA setups, chip-to-chip latency sits around 4,000 nanoseconds, whereas the theoretical physics limit governed by the speed of light is just two to three nanoseconds. Etched views this vast gap, along with ultra-low voltage operation and massive cluster scale-outs, as an opportunity to rethink how hardware is built. Gavin envisions futuristic "mega token factories"—monolithic, $40 billion facilities designed like modern semiconductor fabs—serving singular models for massive populations to unlock ultimate economies of scale.

* **Mathematical Breakthroughs:** AI models have already begun proving complex college-level conjectures, but accelerating their speed ten-fold shrinks multi-generational problems into humanly observable timelines. * **Wall Clock Time Reduction:** High-throughput, low-latency decode shifts year-long compute runs down to one month, month-long runs to three days, and three-day runs to under seven hours. * **Latency Benchmarks:** Standard chip-to-chip interconnects operate at ~4,000 nanoseconds, compared to physical speed-of-light limits of 2–3 nanoseconds. * **Scale-Up Domains:** The industry transitioned from 8-chip scale-up domains to 72-chip architectures (such as NVIDIA's NVL72), with future cluster scale-outs moving toward single-site gigawatt token factories.

---

`48:38` The Evolution of Kernel Engineering and Software Strategy

Kernel engineering—the art of writing low-level code to optimize math primitives like matrix multiplications (`matmul`), convolutions, and chip-to-chip collectives directly on raw silicon—has evolved from a niche discipline into a vital bottleneck for AI performance. Gavin notes that optimization at the kernel layer typically yields 3% to 4% performance improvements per iteration. Rather than building software intended primarily for human coders, Etched designs its profiling tools, debugging stacks, and software infrastructure around how future AI coding models will interact with them. In internal tests, an AI coding model using OpenAI's Codex successfully brought up `gpt-oss` overnight from scratch using only Etched's developer documentation.

Etched deliberately avoided the common industry path of building arbitrary graph compilers to support generalized PyTorch, CUDA, or ONNX graphs. Gavin and Rob recognized that building a general-purpose compiler requires enormous engineering resources while yielding suboptimal performance. Instead, they placed a "kernels-first" bet on the premise that fewer than 100 core AI models will truly matter globally, all sharing similar underlying mathematical primitives.

> "We are kernels-first programming, and that means that, for a long time, it did not work out of the box. But if you were a kernels expert, you could get incredibly, incredibly high performance."

* **Kernel Optimizations:** Overlapping compute primitives and fine-tuning memory allocation typically yields incremental 3–4% speed improvements per optimization. * **Software Design Choice:** Etched chose direct kernel access over graph compilers, avoiding the abstraction overhead seen in standard PyTorch or CUDA stacks. * **High-Frequency Trading Synergy:** Early skepticism from general software developers contrasts with rapid adoption by high-frequency trading (HFT) engineers, who routinely bypass compilers to write bare-metal code; dozens of HFT engineers subsequently joined Etched. * **Model Spectrum:** The architecture assumes that under 100 high-value model architectures will dominate global AI workloads.

---

`52:44` Vertical Integration and the Focus on Token Capacity

Etched operates under the guiding principle that "production is the product." In an inference-dominated market, the company that brings the highest volume of token throughput online at the lowest latency will capture the greatest enterprise value. To achieve maximum scale without overextending, Etched strictly delineates where to vertically integrate and where to rely on partners. They design complete rack-level architectures, power delivery systems, and bespoke board assemblies rather than selling standalone chips, but they deliberately avoid capital-intensive infrastructure like building their own physical data centers.

``` +-------------------------------------------------------------------+ | Model Layer (Top) | | (High Economies of Scale: Frontier Labs) | +-------------------------------------------------------------------+ | Etched Integrated Stack | | +-----------------------------------------------------------+ | | | Kernel Programming & Software Tools | | | | Custom Server Rack Architecture & Power Delivery | | | | Board Design & Interconnect Systems | | | | Purpose-Built ASICs (ASIC Silicon) | | | +-----------------------------------------------------------+ | +-------------------------------------------------------------------+ | Chip Fabrication (Bottom) | | (High Economies of Scale: Foundries/TSMC) | +-------------------------------------------------------------------+ ```

Addressing the dynamic where hyperscalers (Google, Meta, Microsoft) and AI labs (OpenAI with project Jalapeno) develop internal silicon, Gavin and Rob point out that custom chips built inside large firms rarely match dedicated hardware companies on raw FLOPS density. Because hyperscalers derive their core profits from search, cloud hosting, or social media, internal chip efforts function primarily as leverage against the "NVIDIA tax" rather than existential imperatives. At Etched, chip performance and token generation are single-minded survival metrics, which allows them to recruit top hardware architects away from major tech firms.

* **Strategic Boundary:** Natural market boundaries sit at the chip/hardware manufacturing layer at the bottom and the model layer at the top; Etched fills the engineering space between the ASIC and the server rack. * **Compute Density:** Hyperscaler internal custom silicon (e.g., Google TPU, Meta MTIA, Microsoft Maya, OpenAI Jalapeno) exhibits lower FP8 FP-density than flagship commercial chips like NVIDIA's Blackwell B300 because internal projects do not face existential market competition. * **Manufacturing Philosophy:** Etched operates via contract electronics manufacturing (CM) models rather than joint development manufacturing (JDM) to retain full control over custom board and power architectures.

---

`55:43` Solving the 50-Picosecond Clock Alignment Crisis

During the verification phase of their Gen-1 silicon, Etched encountered a critical hardware anomaly that nearly derailed the project. While digital logic had been extensively verified using a massive FPGA cluster, analog behavior across clock domain crossings could not be fully simulated on FPGAs. When prototype silicon returned from the fab, the engineering team discovered data corruption caused by backpressure logic failing across different clock domains, leading to incorrect calculations.

Resolving the defect required aligning two independent clock signals on the chip to within 50 picoseconds (50 trillionths of a second)—performing this alignment reliably across two billion cycles per second on every production chip. Several senior engineers declared the problem physically impossible and resigned from the company. Gavin led a two-week crunch, designing a phase-drifting mechanism that dynamically monitors clock phase variations, waits for precise alignment intervals, and locks the phase relationships permanently.

``` Clock Signal A: --|____|----|____|----|____|-- Clock Signal B: ---|____|----|____|----|____|- <----> Target: < 50 Picoseconds Drift Window ```

* **FPGA Limitation:** FPGAs validate digital logic but cannot replicate real-world analog timing, thermal noise, or clock domain crossing dynamics. * **Precision Target:** Required clock phase alignment down to 50 picoseconds ($50 \times 10^{-12}$ seconds) executing 2,000,000,000 times per second ($2\text{ GHz}$). * **Resolution Window:** The core engineering fix was conceptualized, simulated, and validated in two weeks. * **Board Bring-Up Execution:** Gavin led three parallel board experiments during chip bring-up; all three succeeded, validating the physical architecture for mass production.

---

`59:30` Navigating Early Fundraising Hurdles

Building custom frontier silicon requires massive upfront capital investments before any physical product can be demonstrated to investors. In early 2024, prior to closing their record-breaking Series A round, Etched reached a critical juncture: the chip architecture and logical designs were complete, but transitioning into the physical design phase required signing multi-million-dollar contractual commitments.

Unlike software startups that can iteratively launch minimum viable products on modest budgets, hardware companies face binary capital risks where underfunding guarantees failure. Gavin and Rob describe the mental intensity of pitching an unproven architectural thesis to cautious venture capital firms, relying entirely on theoretical benchmarks and simulations to convince investors to back a team of young founders taking on established semiconductor giants.

* **Capital Thresholds:** Entering the physical design (tape-out prep) phase requires binding commitments worth millions of dollars before physical silicon exists. * **Fundraising Dynamics:** Early-stage hardware financing relies on convincing investors of architectural superiority and execution speed prior to having physical silicon to demonstrate.

`01:00:00` The Series A Crunch: "How the Hell Are We Going to Pull This Off?"

By late 2023, Gavin Uberti and Rob Wachen confronted a daunting financial reality. They realized that running massive Mixture-of-Experts (MoE) AI models meant they could not just build a standalone chip; they needed to construct an entire integrated cluster—boards, interconnects, cold plates, and complex networking. They had $15 million in the bank, but physical design vendors alone would cost $40 to $50 million, and they estimated needing $100 million over the next 12 months to reach scale without resorting to a slow test-chip phase. Gavin recalls looking at the numbers and nervously wondering how hard it would be to go back to Harvard.

To prove their vision, they drafted a grueling, highly technical 30-page memo detailing their execution milestones, market projections, new use cases, and token-cost modeling. Despite their preparation, every major venture capital firm in Silicon Valley initially passed. Investors were hesitant: two young founders straight out of Harvard who had never taped out a chip, pursuing an unproven inference market when most assumed the future was all about training. At the time, the record for a semiconductor Series A was roughly $50 million. To survive on a shoestring budget, Gavin joke-planned a absolute minimum $30 million budget where he would eat nothing but ramen while paying strictly for the mask of an 11mm tape-out.

``` +-------------------------------------------------------------------------+ | THE FINANCING SCALED-UP | | | | $15M initial bank balance ---> $30M extreme bare-bones "ramen" plan | | | | | v | | $100M+ raised for full cluster Series A | +-------------------------------------------------------------------------+ ```

Survival mode kicked in. The founders worked late into their Cupertino office, scrutinizing every $100,000 expense item and calling every possible contact to piece together funding. Small commitments began trickling in—$1 million here, $5 million for FPGAs there—catalyzed in part by a venture debt provider willing to cross the chip-threshold with them. Ultimately, they brought a spreadsheet with $103 million in soft commits to their board meeting and decided to take it, securing the largest AI chip Series A in history.

- Every major Silicon Valley VC passed on Etched's initial Series A pitch. - The previous record for a semiconductor Series A was approximately $50 million. - Etched assembled $103 million in soft commitments to fund their complete cluster development. - Key suppliers stepping in were critical: Synopsis provided emulators on favorable, multi-year payment terms that functioned like a major loan.

`01:05:00` Winning Over TSMC and the "Contrarian and Right" Paradox

Etched’s relationship with TSMC began before they had raised their $100 million Series A. Gavin was invited as a novelty speaker to a semiconductor industry event, where he was the only presenter under 40 (and at the time, just 22 years old). At the post-event dinner, seated among suit-wearing industry veterans including the former CEO of Arm, Gavin sat next to a senior TSMC Vice President. Discovering they had both studied mathematics in college, they pulled out a piece of paper and dived deep into how modern AI models operate at a precise tensor-by-tensor level and why global memory bandwidth was critical. The next day, TSMC emailed saying they wanted to find a way to work with Etched.

> "When you read about investing, everyone cites this idea of like 'contrarian and right' as the quadrant that makes all the money... But contrarian means like everyone else thinks you're stupid. And so when you go and you get an immediate no from literally everybody, it is a fascinating quadrant to exist in before you become consensus."

The host, a lead investor in Etched, breaks the fourth wall to discuss the nature of early-stage investing in high-risk hardware. Traditional semiconductor and coding venture funds missed major AI trends because they relied on historical base rates—recalling 20 years of failed tape-outs and forgetting that modern EDA tools and high-performance FPGAs had transformed chip validation. Etched’s early backers fell into two camps: pure believers in the team and market, or hyper-technical practitioners like high-frequency trading firms whose engineers audited every detail of the micro-architecture, RTL, board designs, and software stack.

- Gavin was the youngest speaker at a major semiconductor conference at age 22. - Traditional chip investors missed AI opportunities by over-indexing on historical semiconductor failure rates. - High-frequency trading firms conducted deep-level technical audits on Etched's RTL, micro-architecture, and hardware schedules before investing.

`01:10:00` "The Puzzle Begins": Silicon Validation and Designing for Gigawatts

A favorite story from the trenches highlights the high-stakes culture required to build custom silicon. A legendary silicon validation engineer joined Etched and led the early stages of "wafer sort"—testing raw silicon wafers with a probe card late at night over the phone with TSMC in Taiwan. When the screen initialized, every single chip square turned red instead of green, signaling absolute failure. Rather than panicking, the veteran engineer leaned back and calmly declared, "The puzzle begins." Within 24 hours, they solved the underlying issue and saw their first green squares.

Looking ahead to Gen 2, Gen 3, and beyond, Etched's primary architecture philosophy centers on three core primitives for running the majority of the world's AI tokens: 1. Building a chip with the maximum FLOPS possible within a fixed power budget. 2. Achieving the lowest inter-chip latency to create the largest possible scale-up domain. 3. Maximizing manufacturing output and sheer product availability.

``` +-------------------------------------------------------------------------+ | ETCHED'S INFERENCE PRIMITIVES | | | | [ Maximum FLOPS / Watt ] + [ Lowest Inter-Chip Latency ] + [ Scale ] | +-------------------------------------------------------------------------+ ```

The team realized that in AI hardware, "the best ability is availability." To deploy at gigawatt scale, Gen 2 is engineered around extreme structural simplicity—reducing total component counts to shorten production cycle times, ensure field serviceability, and avoid supply chain bottlenecks. Rather than directly competing for the exact same supply chain nodes as NVIDIA's Rubin architecture (such as 3nm and specific HBM generations), Etched strategically built on different fabrication nodes (like 4nm) and alternate memory supply lines. This turned supply acquisition into a positive-sum game for large data center customers who want to deploy multiple gigawatts of compute across distinct platforms.

- During initial wafer sort, every test square initially flashed red before the team diagnosed and fixed the issue within 24 hours. - Etched's Gen 1 product avoids direct supply conflicts with NVIDIA Rubin by utilizing a 4nm TSMC process and distinct HBM configurations. - Gen 2 design prioritizes physical simplicity to enable rapid, gigawatt-per-month production capabilities.

<ElicitationsGroup message="Explore more about Etched's technical bets and business strategy:"> <Elicitation label="Examine the technical architecture behind Etched's low-voltage inference" query="Tell me more about how Etched uses low-voltage inference and custom memory architectures to maximize FLOPS per watt."/> <Elicitation label="Learn about Etched's recruitment strategy for top engineering talent" query="How did Etched convince industry legends and top 22-year-old engineers to join their hardware team?"/> </ElicitationsGroup>

Here is the detailed walkthrough of the transcript section.

---

`01:15:00` Rethinking Hardware for Non-Human Intelligence

Hardware design directly shapes the trajectory and capabilities of future AI models. The central insight is that machines do not think like humans, just as airplanes do not fly like birds. In biological brains, storing memory and accessing data are remarkably cheap for neurons, whereas doing complex math is energy-intensive and slow. For silicon chips, the exact opposite is true: moving data is extremely expensive while performing mathematical operations is exceptionally cheap. Furthermore, due to fundamental limits in DRAM technology, math will continue to get cheaper at a faster rate than memory access.

Because compute is cheap, model builders should lean heavily into massive compute scaling. Instead of shying away from dense math, future architectures should embrace running many concurrent model copies, activating massive numbers of experts, or spreading gigantic Expert blocks across multiple server racks at once. While current efficient inference trends focus on saving memory—such as avoiding loading full contexts—true superintelligence will demand reading through a billion tokens of context instantly and attending to vast repositories of knowledge in short-term memory.

To enable this, hardware must adapt to increasing model "dynamism." Modern architectures, like Mixture-of-Experts (MoE), require routing computation and memory at a per-token or per-user level. Instead of processing every token with every parameter, dynamic chips allow tokens to share context memory to eliminate overhead, extend context length for high-importance tokens, and dynamically route data to other chips on the fly. Existing legacy hardware incurs huge performance penalties when handling these dynamic workloads, forcing operators into a choice between massive software overhead or using rigid, blocky architectures that apply blunt force compute where finer control is required.

---

`01:18:01` Scaling Agent Fleets and the Shift in Global Productivity

The nature of AI evaluation and agent deployment is fundamentally shifting as models transition from short tasks to long-horizon workflows. Referencing a viral tweet by Noam Brown (who has since joined Etched as an angel investor), tasks with six-month time horizons are traditionally impractical to evaluate because newer models render the test obsolete before it finishes. With cluster-scale memory technology, long-horizon evaluations can be compressed dramatically. However, solving grand challenges is not just about running a single model faster—it is about scaling agent fleets. A single human cannot build a rocket, but a coordinated team can; similarly, tackling complex software or engineering tasks will require dynamic teams of agents ranging from ten to a million, necessitating both ultra-fast token latency and massive cluster FLOPs.

In the long run, AI inference is poised to become the majority of global GDP. While society currently measures economic productivity as GDP per capita, future output will likely be measured in "agents per megawatt" or "agents per gigawatt." Within a few years—potentially as early as 2027—the majority of the knowledge workforce will be composed of AI agents rather than human workers. National energy strategies will shift heavily toward dedicating data center power to inference, where a country's energy efficiency directly dictates its total agent workforce and economic output.

* **Agent Workforce Projections:** By 2027, knowledge-work AI agents are projected to outnumber human workers globally. * **Civilization-Scale Scale-Up:** Sovereign entities will run up to a billion concurrent 24/7 AI agents, representing the largest technology proliferation in human history. * **Economies of Scale in Brains:** Similar to how human brains only activate specific regions at any given moment, giant distributed Mixture-of-Experts (MoE) models only activate small parameter subsets per token. By routing massive user volumes across distributed hardware clusters, the cost per thought drops significantly.

---

`01:23:44` The Trillion-Dollar Data Center and the Race for Tokens

The physical infrastructure powering AI will scale to unprecedented levels, eventually leading to individual trillion-dollar data centers. Just as semiconductor manufacturing progressed through 10-billion and 100-billion-dollar fabs to push down wafer costs, token-generation facilities will undergo massive vertical expansion. The cost to produce a unit of machine intelligence remains vastly lower than the economic value that intelligence generates, creating a multi-decade supply shortage of tokens.

In this paradigm, market value will concentrate in companies that supply and optimize the token production supply chain—from model design down to custom silicon. Furthermore, scaling systems must offer compounding returns rather than linear costs: doubling token throughput cannot simply mean buying double the servers linearly, but must leverage cluster-scale memory and interconnect architectures to lower the marginal cost per token as clusters grow bigger.

* **Core Economic Thesis:** Thinking is the foundational input for every company; machine intelligence offers a multi-decade supply-shortage opportunity. * **Cluster Economics:** Hardware scaling must deliver sub-linear cost increases for token output through shared, cluster-wide hardware efficiency rather than basic 1:1 hardware additions.

---

`01:26:19` The Kindest Thing

When asked for his personal "kindest thing" story, Rob Wachen shares a pivotal moment from his adolescence during his treatment for cancer. At 16 years old, his doctors presented him with a life-altering choice: undergo surgery, which offered a higher chance of survival but carried the certainty that he would never walk again, or undergo radiation, which preserved his ability to walk but carried a lower probability of survival. His parents empowered him to make the decision himself, and he chose the surgery.

Following the procedure, a necrosis analysis of the removed tumor showed that his cell death percentage fell below the required 98–99% threshold, meaning he required urgent specialized radiation therapy. Only a few machines in the world could perform the necessary procedure, with one located in Boston. While Rob was bound to a wheelchair, both of his parents made the sacrifice to drop everything in their personal and professional lives to move to Boston with him for several months to support his recovery—an act of selflessness for which he remains eternally grateful.

## Notable quotes > `02:07` A few years ago, when they set out to build a better AI chip than the largest companies in the world, almost everyone I called told me it could not be done. — Patrick O'Shaughnessy

> `07:52` If I 2x my voltage, my power goes up by 4x. If I cut my voltage in half, my power goes down by a quarter... we were able to create a new mechanism of running at much lower voltages, a new type of power delivery that we call low voltage inference. — Gavin Uberti

> `48:38` We are kernels-first programming, and that means that, for a long time, it did not work out of the box. But if you were a kernels expert, you could get incredibly, incredibly high performance. — Gavin Uberti

> `01:45:00` When you read about investing, everyone cites this idea of like 'contrarian and right' as the quadrant that makes all the money... But contrarian means like everyone else thinks you're stupid. And so when you go and you get an immediate no from literally everybody, it is a fascinating quadrant to exist in before you become consensus. — Patrick O'Shaughnessy

## Mentioned Gavin Uberti, Rob Wachen, Etched, Patrick O'Shaughnessy, Ramp, Felix, Rogo, WorkOS, OpenAI, Perplexity, Cursor, Positive Sum, PSUM.VC, ChatGPT, NVIDIA, Mark Ross, Cypress Semiconductor, Denard scaling, Blackwell, Vanta, Harvey, Ridgeline, GPT-4, Prod, Anysphere, Mercor, Xnor.ai, Apple, OctoML, Sanford, FIRST Tech Challenge, Brian Kelleher, HGX, DGX, TSMC, NVL72, Codex, gpt-oss, PyTorch, CUDA, ONNX, NVIDIA Blackwell B300, NVIDIA Rubin, OpenAI Jalapeno, Google TPU, Meta MTIA, Microsoft Maya, Arm, Synopsis, Noam Brown

[Source](https://traffic.megaphone.fm/CLS8561569864.mp3)
